Multi Function Time Relay AOT-T8-M Series

Multi Function Time Relay AOT-T8-M Series

Model: AOT-T8-M
Original: China
In Stock: Yes
Warranty: one year
Product description: Multifunction time relay can be used for electrical appliances, control of lights, heating, motors, pumps and fans (10 functions, 10 time ranges, multi-voltage)
INQUIRY

Multi Function Time Relay AOT-T8-M Series

Applications

-Multifunction time relay can be used for electrical appliances, control of lights, heating, motors, pumps and fans (10 functions, 10 time ranges, multi-voltage).
Function Features

-10 functions: – 5 time functions controlled by supply voltage

-4 time functions controlled by control input

-1 function of latching relay

-Comfortable and well-arranged function and time-range setting by rotary switches.
-Time scale 0.1 s – 10 days divided into 10 ranges.

-Relay status is indicated by LED.
-1-MODULE,DIN rail mounting.

AOT-T8-M
Rated control supply voltage: A230:AC230V W240:AC/DC12V-240V
Number of contacts
1:1×SPDT
2:2×SPDT

Electrical features

Model Meaning	GRT8-M1 (1SPDT) GRT8-M2 (2SPDT)
Supply Indication	Green Led
Output Indication	Red Led
Voltage Range	AC230V (A230) OR AC/DC12V-240V (W240)
Output	1SPDT or 2 SPDT
Supply Terminals	A1-A2
Time Range	0.1s-10 days,ON,OFF
Time Setting	Potentionmeter
Rated Frequency	50/60HZ
Rated Current	16A
Weight/pcs	0.1KG/PCS
Standard	IEC6947-5-1 EN61812-1
Certifications	CE CB CCC TUV
Warranty/guarantee	18months
MOQ	1PCS
